Jacquard Connect CAD Software Development Kit | NedGraphics​
Jacquard Connect is our advanced Software Development Kit (SDK) designed to simplify jacquard software integration and improve communication between weaving design software and electronic Jacquard controller software. Acting as a digital connector, Jacquard Connect streamlines the design-to-production process, ensuring faster, more precise, and more reliable weaving operations.
Designers can now send 'card' files (JC5/EP) directly to Jacquard controllers, eliminating the need for physical media like floppy disks or USB drives. This innovation reduces manual uploads in the weaving room and optimizes weaving software integration for modern workflows.
Jacquard Connect allows customers to build personalized user interfaces, making it possible to adapt workflows while still leveraging the proven power of NedGraphics technology. It is the perfect tool for teams looking to configure jacquard programming software to their unique business needs.
Automate the conversion of designs for different harnesses or tie-ups. The same design can be applied across multiple looms without manual adjustments—reducing errors, saving time, and supporting smoother, error-free digital Jacquard weaving production.
For Staubli Jacquard controllers, loom parameters can be embedded directly into JC5 files, ensuring that accurate settings are applied during production. This results in consistent, high-quality output across every Jacquard loom computer setup.
Jacquard Connect acts as a vital adapter, ensuring your design-to-production workflow is optimized by enhancing productivity, reducing manual intervention, and maintaining consistent quality. This versatile solution supports Staubli controllers, Bonas controllers, and some Picanol Dobby machines, making it the ideal digital nexus for designers and manufacturers seeking to streamline their weaving operations.
Jacquard Connect is the ideal solution that empowers business operations leaders to transform their production workflows. Customers can develop their own custom user interfaces, offering a tailored experience that fits their exact needs.
This solution is not included in the automated updates and is billed separately. Please feel free to contact us for further details.
